SKF P2BTSS 20M-YTPSS Ball bearing units

SKF P2BTSS 20M-YTPSS Ball bearing units

Product Code: P2BTSS 20M-YTPSS
Part/No: 042124
Brand: SKF
Short base pillow (plummer) block ball bearing units consist of an insert bearing mounted in a stainless steel housing. This variant has threads for attachment bolts and is suitable for applications with both constant and alternating directions of rotation. It has an inner ring extended on both sides and is locked onto the shaft by tightening a set screw on the inner ring, making it easy to mount.
Ready to mount
Lubricated and sealed bearing
Quick locking onto the shaft
Good corrosion resistance
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Shaft diameter 20 mm
Performance
Basic dynamic load rating 10.8 kN
Basic static load rating 6.55 kN
Limiting speed 5,000 r/min
Properties
Centre height pillow block 33.3 mm
Bearing width total 31 mm
Centre distance between bolt holes 50.8 mm
Housing overall width 29 mm
Note Limiting speed with shaft tolerance h6
Housing type Pillow block
Sealing type Contact, gutter
Bore type Cylindrical
Lubricant Grease
Material housing Stainless steel
Fastening bolt hole type Threaded
Housing type 4 Pillow block
Number of bolt holes for fasteners 2
Relubrication hole Without
Grease fitting Without
Retaining feature inner ring Set screws
Rubber seating ring Without
Sealing bearing Seal and flinger on both sides
Sealing unit Optional end cover
Coating Without
Material bearing Stainless steel
Logistics
Pack gross weight 0.485 kg
eClass name Bearing with spherical outside surface
EAN 7316577847324
Product net weight 0.998 kg
