SKF SYF 50 FM Ball bearing units

SKF SYF 50 FM Ball bearing units

Product Code: SYF 50 FM
Part/No: Eshop020009
Brand: SKF
Short base pillow (plummer) block ball bearing units consist of an insert bearing mounted in a cast iron housing that can be bolted to a support surface. This variant is intended for use in applications where the direction of rotation is constant. It has a narrow inner ring and is locked onto the shaft by an eccentric locking collar, making it easy to mount.
Strong
Narrow design
Ready to mount
Lubricated and sealed bearing
Designed for rotation in one direction
Accommodate static initial misalignment
€281.95
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Shaft diameter 50 mm
Performance
Basic dynamic load rating 35.1 kN
Basic static load rating 23.2 kN
Limiting speed 4,000 r/min
Properties
Centre height pillow block 57.2 mm
Bearing width total 43.7 mm
Centre distance between bolt holes 101.6 mm
Housing overall width 54 mm
Note Limiting speed with shaft tolerance h6
Housing type Pillow block
Sealing type Contact, standard
Bore type Cylindrical
Lubricant Grease
Material housing Cast iron
Fastening bolt hole type Threaded
Housing type 4 Pillow block
Number of bolt holes for fasteners 2
Relubrication hole With
Grease fitting With
Retaining feature inner ring Eccentric collar
Rubber seating ring Without
Sealing bearing Seal on both sides
Sealing unit Without
Coating Without
Material bearing Bearing steel
Logistics
Pack gross weight 2.394 kg
eClass name Bearing with spherical outside surface
EAN 7316571171722
Product net weight 1946.4 g
