SKF SONL 232-532 Bearing housings

SKF SONL 232-532 Bearing housings

Product Code: SONL 232-532
Part/No: Eshop019830
Brand: SKF
SONL pillow (plummer) block housings are specially designed for oil lubrication. They can accommodate high temperatures and bearings operating at high speeds. They have a strong, stiff design and are characterized by a number of built-in features that maximize the effects of the lubricant and extend bearing service life.
Designed for oil lubrication
Can accommodate high temperatures
Can accommodate high bearing operating speeds
Robust design
Long service life
€7,418.66
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Performance
Properties
Centre distance between bolt holes axial direction 120 mm
Width of bearing seat 104 mm
Centre height pillow block 215 mm
Centre distance between bolt holes 470 mm
Diameter of bearing seat 290 mm
Attachment bolt diameter 30 mm
Housing type Plummer/pillow block
Housing configuration Twopiece
Material housing Cast iron
Bearing housing seal type Oil seal
Housing configuration 3 Twopiece
Housing type 4 Plummer/pillow block
Mounting arrangement Through shaft/Shaft end
Number of bolt holes for fasteners 4
Housing lubrication feature possibility Oil
Logistics
Pack gross weight 119 kg
eClass name Plummer block housing
EAN 7316572186077
Product net weight 74.3 kg
