SKF PHC 100H-1CX10FT Power Transmission Chains

SKF PHC 100H-1CX10FT Power Transmission Chains

Product Code: PHC 100H-1CX10FT
Part/No: Eshop027554
EAN: 0731657261306
Brand: SKF
Chains are critical components in power transmission systems. Robust, quality chain drives extend mean time between failures, which reduces maintenance costs. SKF chains are manufactured in state-of-the-art facilities with tight quality controls. The cotter pin type can be disassembled and replaced easily. The riveted type provides a very strong link, and has a similar fatigue strength as the other links in the chain.
Provide a strong chain
Cost-effective
Reduce maintenance
Extend the mean time between failures
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Pitch 31.75 mm
Roller diameter max 19.05 mm
Pin diameter max 9.53 mm
Plate height max 30 mm
Plate thickness max 4.8 mm
Width between inner plates min 18.9 mm
Width between inner plates min2 18.9 mm
Properties
Standard ANSI
Chain number 100H1C
Weight per meter 4.52 kg
Logistics
EAN code 07316572613061
Product net weight 13.435 kg
eClass name Chain drive (unclassified)
Pack gross weight 13.7 kg
