SKF BC1B 326120/HB1 Cylindrical roller bearings

SKF BC1B 326120/HB1 Cylindrical roller bearings

Product Code: BC1B 326120/HB1
Part/No: Eshop010024
Brand: SKF
Single row cylindrical roller bearings are designed to accommodate high to very high radial loads in combination with medium to high speeds. The NJZ design is based on the NJ design, but does not have a lead-in chamfer on the inner ring. Compared to NJ bearings, NJZ bearings can therefore accommodate a somewhat larger axial displacement. However, they lack the mounting advantages of the lead-in chamfer.
High to very high radial load carrying capacity
Low friction
Long service life
Locate the shaft axially in one direction
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 40 mm
Outside diameter 94 mm
Width 30 mm
Performance
Basic dynamic load rating 125 kN
Basic static load rating 129 kN
Limiting speed 4,800 r/min
Reference speed 3,600 r/min
Properties
Sealing Without
Bore type Cylindrical
Cage Without
Locating feature bearing outer ring None
Lubricant None
Number of rows 1
Radial internal clearance C4
Relubrication feature Without
Tolerance class Normal
Bearing part Complete bearing
Number of flanges inner ring 1
Number of flanges outer ring 2
Coating Without
Axial displacement capability In one direction
Logistics
Pack gross weight 1.035 kg
eClass name Cylindrical roller bearing
EAN 7316570960952
Product net weight 1.21 kg
