SKF NJ 2216 ECN1ML/C3 Cylindrical roller bearings

SKF NJ 2216 ECN1ML/C3 Cylindrical roller bearings

Product Code: NJ 2216 ECN1ML/C3
Part/No: Eshop014167
Brand: SKF
Single row cylindrical roller bearings are designed to accommodate high to very high radial loads in combination with medium to high speeds. The SKF assortment includes many designs and variants, such as standard, full complement and high capacity bearings. Depending on the configuration of the outer and inner rings, the bearings are available in locating as well as non-locating designs.
High to very high radial load carrying capacity
Low friction
Long service life
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 80 mm
Outside diameter 140 mm
Width 33 mm
Performance
Basic dynamic load rating 212 kN
Basic static load rating 245 kN
Limiting speed 8,500 r/min
Reference speed 5,300 r/min
Properties
SKF performance class SKF Explorer
Sealing Without
Bore type Cylindrical
Cage Machined metal
Locating feature bearing outer ring Locating slot
Lubricant None
Number of rows 1
Radial internal clearance C3
Relubrication feature Without
Tolerance class Normal
Bearing part Complete bearing
Number of flanges inner ring 1
Number of flanges outer ring 2
Coating Without
Axial displacement capability In one direction
Logistics
Pack gross weight 2.306 kg
EAN 7316572647813
Product net weight 2.2 kg
