SKF NJF 2236 ECJA/L4BC3VR203 Cylindrical roller bearings

SKF NJF 2236 ECJA/L4BC3VR203 Cylindrical roller bearings

Product Code: NJF 2236 ECJA/L4BC3VR203
Part/No: Eshop014754
Brand: SKF
Single row cylindrical roller bearings are designed to accommodate high radial loads in combination with high speeds. Having two integral flanges on the outer ring and one on the inner ring, NJF design bearings can accommodate axial displacement in one direction. A retaining ring on the inner ring provides a shoulder to hold the bearing components in place. The retaining ring should not be loaded axially during operation.
High radial load carrying capacity
Low friction
Long service life
Locate the shaft axially in one direction
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 180 mm
Outside diameter 320 mm
Width 86 mm
Performance
Basic dynamic load rating 1,250 kN
Basic static load rating 1,700 kN
Limiting speed 2,800 r/min
Reference speed 2,200 r/min
Properties
SKF performance class SKF Explorer
Sealing Without
Bore type Cylindrical
Cage Sheet metal
Locating feature bearing outer ring None
Lubricant None
Number of rows 1
Radial internal clearance C3
Relubrication feature Without
Tolerance class Normal
Bearing part Complete bearing
Number of flanges inner ring 1
Number of flanges outer ring 2
Coating Without
Logistics
Pack gross weight 33.547 kg
eClass name Cylindrical roller bearing
EAN 7316579719193
Product net weight 44.76
