SKF NNU 4164 F/C3 Cylindrical roller bearings

SKF NNU 4164 F/C3 Cylindrical roller bearings

Product Code: NNU 4164 F/C3
Part/No: Eshop015239
Brand: SKF
Double row cylindrical roller bearings are designed to accommodate high radial loads in combination with high speeds. Having three flanges on the outer ring and no flanges on the inner ring, NNU design bearings can accommodate axial displacement in both directions. An important feature is the separable design, which facilitates mounting and enables the bearing components to be interchanged.
High radial load carrying capacity
Low friction
Long service life
Separable design
Accommodate axial displacement in both directions
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 320 mm
Outside diameter 540 mm
Width 218 mm
Performance
Basic dynamic load rating 3410 kN
Basic static load rating 6200 kN
Limiting speed 1.300 r/min
Reference speed 1.000 r/min
Properties
Sealing Without
Bore type Cylindrical
Cage Sheet metal
Locating feature bearing outer ring None
Lubricant None
Number of rows 2
Radial internal clearance C3
Relubrication feature Without
Bearing part Complete bearing
Number of flanges outer ring 3
Coating Without
Axial displacement capability In both directions
Logistics
EAN code 07316570105230
Product net weight 201.943 kg
eClass name Cylindrical roller bearing
