SKF NU 217 ECN1ML/C3H Cylindrical roller bearings

SKF NU 217 ECN1ML/C3H Cylindrical roller bearings

Product Code: NU 217 ECN1ML/C3H
Part/No: Eshop015696
Brand: SKF
Single row cylindrical roller bearings are designed to accommodate high to very high radial loads in combination with medium to high speeds. The SKF assortment includes many designs and variants, such as standard, full complement and high capacity bearings. Depending on the configuration of the outer and inner rings, the bearings are available in locating as well as non-locating designs.
High to very high radial load carrying capacity
Low friction
Long service life
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 85 mm
Outside diameter 150 mm
Width 28 mm
Performance
Basic dynamic load rating 190 kN
Basic static load rating 200 kN
Properties
SKF performance class SKF Explorer
Sealing Without
Bore type Cylindrical
Cage Machined metal
Locating feature bearing outer ring Locating slot
Lubricant None
Number of rows 1
Radial internal clearance C3H
Relubrication feature Without
Tolerance class Normal
Bearing part Complete bearing
Number of flanges outer ring 2
Coating Without
Axial displacement capability In both directions
Logistics
Pack gross weight 2.129 kg
EAN 7316576172748
Product net weight 2.094 kg
