SKF NUH 2234 ECMH/L4BC3VR203 Cylindrical roller bearings

SKF NUH 2234 ECMH/L4BC3VR203 Cylindrical roller bearings

Product Code: NUH 2234 ECMH/L4BC3VR203
Part/No: Eshop016503
Brand: SKF
Single row cylindrical roller bearings are designed to accommodate high to very high radial loads in combination with medium to high speeds. The SKF assortment includes many designs and variants, such as standard, full complement and high capacity bearings. Depending on the configuration of the outer and inner rings, the bearings are available in locating as well as non-locating designs.
High to very high radial load carrying capacity
Low friction
Long service life
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 170 mm
Outside diameter 310 mm
Width 86 mm
Performance
Basic dynamic load rating 1,160 kN
Basic static load rating 1,530 kN
Limiting speed 2,800 r/min
Reference speed 2,200 r/min
Properties
SKF performance class SKF Explorer
Sealing Without
Bore type Cylindrical
Cage Machined metal
Locating feature bearing outer ring None
Lubricant None
Number of rows 1
Radial internal clearance C3
Relubrication feature Without
Tolerance class Normal
Bearing part Complete bearing
Number of flanges outer ring 2
Coating Without
Design Separable
Axial displacement capability In both directions
Logistics
Pack gross weight 33.981 kg
eClass name Cylindrical roller bearing
EAN 7316576834196
Product net weight 1.335 kg
