SKF NUP 309 ECNJ/C3VM004 Cylindrical roller bearings

SKF NUP 309 ECNJ/C3VM004 Cylindrical roller bearings

Product Code: NUP 309 ECNJ/C3VM004
Part/No: Eshop016782
Brand: SKF
Single row cylindrical roller bearings are designed to accommodate high radial loads in combination with high speeds. Having two integral flanges on the outer ring and one integral flange and one loose flange ring on the inner ring, NUP design bearings can locate the shaft axially in both directions. An annular groove in the outer ring enables the bearings to retain a snap ring. An important feature is the separable design, which facilitates mounting and enables the bearing components to be interchanged.
High radial load carrying capacity
Low friction
Long service life
Locate the shaft axially in both directions
Separable design
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 45 mm
Outside diameter 100 mm
Width 25 mm
Performance
Basic dynamic load rating 112 kN
Basic static load rating 100 kN
Limiting speed 8,500 r/min
Reference speed 7,500 r/min
Properties
Sealing Without
Bore type Cylindrical
Cage Sheet metal
Locating feature bearing outer ring Snap ring groove
Lubricant None
Number of rows 1
Radial internal clearance C3
Relubrication feature Without
Tolerance class Normal
Bearing part Complete bearing
Number of flanges inner ring 1
Number of flanges outer ring 2
Coating Without
Axial displacement capability None
Logistics
Pack gross weight 945.7 g
EAN 7316570979367
Product net weight 0.932 kg
