SKF R 314485 A Cylindrical roller bearings

SKF R 314485 A Cylindrical roller bearings

Product Code: R 314485 A
Part/No: Eshop018172
Brand: SKF
Four-row cylindrical roller bearings are designed to accommodate very heavy radial loads in combination with medium to high speeds. The SKF assortment includes many designs and variants, such as bearings with a cage and full complement bearings. Depending on the configuration of the outer and inner rings, the bearings are available in locating as well as non-locating designs.
Exceptional high radial load carrying capacity
Low friction
Long service life
Low cross-sectional height
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 378 mm
Outside diameter 480 mm
Width 350 mm
Performance
Basic dynamic load rating 4,570 kN
Basic static load rating 11,000 kN
Limiting speed 1,400 r/min
Reference speed 950 r/min
Properties
Sealing Without
Bore type Cylindrical
Cage Machined metal
Locating feature bearing outer ring None
Lubricant None
Number of rows 4
Relubrication feature With
Bearing part Bearing without inner ring
Number of flanges outer ring 5
Coating Without
Logistics
Pack gross weight 170.47 kg
EAN 7316577125682
Product net weight 50.025 kg
