SKF SYF 510 Housings for insert bearings

SKF SYF 510 Housings for insert bearings

Product Code: SYF 510
Part/No: Eshop020012
Brand: SKF
Short base pillow (plummer) block housings are designed to accommodate an insert bearing. They are strong, stiff and cost-effective, and are suitable for most applications. The housings has threads for attachment bolts so that it can be bolted directly to a support surface.
Accommodate heavy loads in different directions
Strong
High degree of stiffness
Narrow design
€41.33
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Housing overall width 54 mm
Centre height pillow block 57.2 mm
Centre distance between bolt holes 101.6 mm
Properties
Coating Without
Housing type Pillow block
Material housing Cast iron
Relubrication hole With
Grease fitting With
Fastening bolt hole type Threaded
Number of bolt holes for fasteners 2
Spherical seating diameter 90 mm
Logistics
EAN code 07316570909845
Product net weight 1.711 kg
eClass name Bearing with spherical outside surface
