SKF SIQ 90 TXE-2LS Rod ends

SKF SIQ 90 TXE-2LS Rod ends

Product Code: SIQ 90 TXE-2LS
Part/No: Eshop019665
Brand: SKF
These SKF rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination. The inner ring is extended on both sides. The bearing requires maintenance and can be relubricated via grease fitting in the housing and for sizes 16 and larger also via the shaft. The female thread is available with a left- (prefix SIL) or right-hand thread.
Easy to relubricate
Suitable for heavy static, alternating or impact loads
Simple and ready-to-mount
Slotted shank with clamping screws
Suitable for hydraulic cylinders
Bearing can be exchanged
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Performance
Basic dynamic load rating 1,370 kN
Basic static load rating 750 kN
Properties
Bore diameter bearing inner ring 90 mm
Centre height housing from end of shank 195 mm
Housing length total 298 mm
Outside diameter housing eye 187.5 mm
Thread designation M 72x3
Width bearing inner ring 60 mm
Width housing eye 73.5 mm
Sealing type Triplelip
Sealing Seal on both sides
Material housing Cast iron
Attachment feature rod end shank Righthand female thread and clamping screws
Sliding contact surface combination Steel/PTFE fabric
Material inner ring Bearing steel
Material outer ring Bearing steel
Maintenance Maintenancefree
Logistics
Pack gross weight 17.705 kg
eClass name Rod end (spherical plain bearing)
EAN 7316577785237
Product net weight 0.019 kg
