SKF 476208-107 C Insert bearings

SKF 476208-107 C Insert bearings

Product Code: 476208-107 C
Part/No: Eshop003941
Brand: SKF
Spherical roller bearings are designed to accommodate heavy radial loads and axial loads in both directions. They can also accommodate misalignment and shaft deflections with virtually no increase of friction or temperature. The insert bearing design includes an inner ring that is extended in one or both directions and equipped with double set screw locking. When the set screws are fully tightened, the shaft is held firmly against the inner ring.
Accommodate misalignment
High load carrying capacity
Low friction
Long service life
Robust
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 36513 mm
Outside diameter 80 mm
Width inner ring 69.85 mm
Width outer ring 23 mm
Performance
Basic dynamic load rating 73.6 kN
Basic static load rating 81.5 kN
Properties
Width total 69.85 mm
Sealing Without
Bore type Cylindrical
Cage Sheet metal
Lubricant None
Relubrication feature With
Outer ring type Cylindrical
Retaining feature inner ring Set screws
Rolling elements Spherical rollers
Coating Without
Material bearing Bearing steel
Logistics
Pack gross weight 1.044 kg
eClass name Spherical roller bearing
EAN 7316577159052
Product net weight 1 kg
