SKF BTM 100 BTN9/DBAVQ496 Super-precision angular contact thrust ball bearings

SKF BTM 100 BTN9/DBAVQ496 Super-precision angular contact thrust ball bearings

Product Code: BTM 100 BTN9/DBAVQ496
Part/No: Eshop010384
Brand: SKF
These double direction angular contact thrust ball bearings consist of two non-separable single row angular contact ball bearings arranged back-to-back. They accommodate axial loads in both directions and offer maximum speed capability. Compared to bearings in the basic design, BTW series, they have a 25% lower bearing height.
Accommodate axial loads in both directions
Maximum speed capability
30° contact angle for higher speeds or 40° contact angle for higher degree of axial rigidty
Suitable for compact arrangements
€0.00
(*The price will be determined)
Tax included
Quantity

100% Shopping Security
  On Request
Dimensions
Bore diameter 100 mm
Outside diameter 150 mm
Performance
Basic dynamic load rating 48 kN
Basic static load rating 116 kN
Properties
Height 45 mm
Contact angle 40 °
Attainable speed for grease lubrication 5,600 r/min
Attainable speed for oilair lubrication 7,100 r/min
Sealing Without
Cage Nonmetallic
Locating feature bearing outer ring None
Lubricant None
Number of rows 2
Relubrication feature Without
Tolerance class NSTD
Coating Without
Material bearing Bearing steel
Design Highspeed (BTM series)
Logistics
Pack gross weight 2.774 kg
eClass name Angular contact thrust ball bearing
EAN 7316576743368
Product net weight 2.647 kg
